Polymaker Fiberon PETG-ESD Filament

Fiberon™ PETG-ESD is an electrostatic discharge-safe filament engineered for use in environments where static control is critical. Designed with carbon nanotube reinforcement, it offers a balance of excellent toughness, chemical resistance, and consistent ESD protection, making it ideal for electronics housings, tooling fixtures, sensor mounts, and other sensitive applications.

Note:  Fiberon™ PETG- ESD is compounded with carbon nano-tubes:
Here is a research regarding ABS compounded with carbon nano-tubes.

 Download the Technical Data Sheet (TDS) to learn more about the material’s detailed performance and specifications.

Printing Settings

Nozzle Temperature: 250 °C – 290 °C

Bed Temperature: 70 °C – 80 °C

Printing Speed: Up to 500 mm/s

Cooling Fan: OFF

Retraction Settings:

Direct Drive:
 • Retraction Distance: 1 mm
 • Retraction Speed: 20 mm/s

Indirect (Bowden) Drive:
 • Retraction Distance: 3 mm
 • Retraction Speed: 40 mm/s

---

Drying Settings

Standard Oven: 65 °C for 3 hours

PolyDryer™: Level 3 for 6 hours

> (Dry only if the material has absorbed moisture).

Do I need to use the cooling fan with Fiberon™ PETG?

It depends on your print priorities:

✅ For maximum strength and layer adhesion:
 Turn OFF the part cooling fan.

✅ For a high-quality surface finish:
 Turn ON the fan (typically at 100%).

🔧 Recommended compromise:
Set the part cooling fan to 20% to achieve a balance between mechanical strength and visual quality.

Spool Dimensions

0.5kg Cardboard Spool
* Inner Hole Diameter: 55 ± 1 mm
* Spool Diameter: 200 ± 1 mm
* Spool Width: 65.6 ± 2 mm
* Spool Weight: 190 ± 7 g

0.75kg Cardboard Spool
* Inner Hole Diameter: 55 ± 1 mm
* Spool Diameter: 200 ± 1 mm
* Spool Width: 50.6 ± 2 mm
* Spool Weight: 125 ± 7 g

1kg Cardboard Spool
* Inner Hole Diameter: 55 ± 1 mm
* Spool Diameter: 200 ± 1 mm
* Spool Width: 65.6 ± 2 mm
* Spool Weight: 140 ± 7 g

2kg Cardboard Spool
* Inner Hole Diameter: 55 ± 1 mm
* Spool Diameter: 250 ± 1 mm
* Spool Width: 117.2 ± 2 mm
* Spool Weight: 370 ± 18.5 g

3kg Cardboard Spool
* Inner Hole Diameter: 55 ± 1 mm
* Spool Diameter: 250 ± 1 mm
* Spool Width: 117.2 ± 2 mm
* Spool Weight: 425 ± 21.3 g

5kg Plastic Spool
* Inner Hole Diameter: 32 ± 1 mm
* Spool Diameter: 300 ± 1 mm
* Spool Width: 160 ± 1 mm
* Spool Weight: 819 ± 30 g
* Spool Material: Polypropylene (PP).
